Raw pivot bracket with no pin for playfield to cabinet support assembly in Data East / Sega / late Stern pinball machines. Mounts to underside of playfield.
Length of bracket is 2 inch from base to center of stud.
Rests on playfield support slide 535-6862-05 which is fastened to the cabinet.
Reference:
500-5329-04
500-5329-00
500-5329-01
500-5329-02
500-5329-03 - 2 inch length to stud center
Capcom
Select manufacturer to view game compatibility
