Williams HOT TIP solid state manual - Original
This product is not currently available.
CALIFORNIA WARNING
This product can expose you to chemicals, including lead and DEHP, which are known to the State of California to cause cancer and birth defects, or other reproductive harm. For more information, go to https://www.p65warnings.ca.gov.
Original Williams HOT TIP solid state version pinball machine manual. Jan 1978. GAME 477. Includes:
USED. Contains notes from previous owner. Sold AS-IS.
Installation
General Game Operation and Scoring
Hot Tip Solid State PROMS
Game adjustments and bookkeeping
Diagnostics Diagrams
Troubleshooting charts
Connector legend
Wire color charts for CPU, Driver Board, Power supply, Master display, Player displays, Back box, Playfield Switches
