IC - 14 pin DIP quad 2 input gate RTL
CALIFORNIA WARNING
This product can expose you to chemicals, including lead and DEHP, which are known to the State of California to cause cancer and birth defects, or other reproductive harm. For more information, go to https://www.p65warnings.ca.gov.
Integrated circuit Hex inverter 14 pin DIP (dual inline package)
2-Input NOR-Function Logic Gate
Circuits Per Package=4
t(PLH) Maximum (S)=12n
P(D) Max.(W) Power Dissipation=100m
Vsup Nom.(V) Supply Voltage=3.6
Package=TO-116
Pins=14
Technology=RTL
The MC824AL features a fully integrated Pierce oscillator to minimize system implementation costs. Other than the addition of a 25-MHz crystal, no external components are required.The crystal selection should be: 25 MHz, parallel resonant type with a load specification of CL = 10 pF. However, crystals with a load specification of CL = 20 pF may be used.
Reference:
MC824AL
