This 92 page factory service manual covers the first GOTTLIEB electronic...
CALIFORNIA WARNING
This product can expose you to chemicals, including lead and DEHP, which are known to the State of California to cause cancer and birth defects, or other reproductive harm. For more information, go to https://www.p65warnings.ca.gov.
92 page factory service manual covers the first GOTTLIEB electronic pinball games.
The System 1 pinball computer is designed around the Rockwell PPS-4/2 microprocessor and was used in the games:
ASTEROID ANNIE
BUCK ROGERS
CHARLIE'S ANGELS
CLEOPATRA
CLOSE ENCOUNTERS
COUNTDOWN
DRAGON
GENIE
HULK
JOKER POKER
PINBALL POOL
ROLLER DISCO
SINBAD
SOLAR RIDE
TORCH
TOTEM
Reference:
GOTSRV2
