48 page manual only for Chicago Coin PLAYLAND RIFLE GALLERY arcade machine...
CALIFORNIA WARNING
This product can expose you to chemicals, including lead and DEHP, which are known to the State of California to cause cancer and birth defects, or other reproductive harm. For more information, go to https://www.p65warnings.ca.gov.
48 page manual only for Chicago Coin PLAYLAND RIFLE GALLERY arcade machine.
Includes sections covering:Lubrication Switch adjustmentsTroubleshootingTrip relay bankScoring motor switch assignmentsTarget reset motor cams & switchesScore motor discStylus Scanning Unit Disc assignmentsClown & Pumpkin unit discAll relay switchesStep-up unitsShot unitnumber unitTarget unitInterlock relaySeries & Operating relaysIllustrated parts
