Bally THE SHADOW pinball machine motor and opto assembly
Reference:
A-19170 motor/opto assy
02-5186 (1) gear
03-7655-4 (1) clamp cable 1/4" dia
14-8014 (1) motor-gear
20-8716-44 (1) pin roll 1/16 x 3/8
4006-01194-02 (1) set screw 6-32 x 1/8 brass tip dog point
4008-01168-10 (4) machine screw 8-32 x 5/8 pl-hh-s
4106-01013-06 (4) sheet metal sscrew No.6 x 3/8 p-ph t-25
A-16908 (1) opto led
A-16909 (1) opto p/t
Select manufacturer to view game compatibility
SHADOW (Bally) Gear
SHADOW (Bally) Gear
Cable clamp Holder 1/4" diameter
Bally THE SHADOW pinball machine mini-playfield motor and gearbox assembly...
1/16" diameter x 3/8" length slotted spring roll pin. Reference: 20-...
Machine Screw 8-32 x 5/8 inch pl-hh-s
Sheet Metal Screw No.6 x 3/8 inch p-ph t-25
Infrared Transmitter assembly in the white plastic housing.
Infrared receiver assembly in the black plastic housing.
SHADOW (Bally) Gear
