WPC pinball machine schematic manual set revised November, 1994. Original...
CALIFORNIA WARNING
This product can expose you to chemicals, including lead and DEHP, which are known to the State of California to cause cancer and birth defects, or other reproductive harm. For more information, go to https://www.p65warnings.ca.gov.
WPC pinball machine schematic manual set revised November, 1994. Original.
20 ledger size 11 x 17 inch fold out pages with sections for:
Power Wiring Diagram
CPU Board Schematic (Used before 4/4/94)
SECURITY CPU Board Schematic (Used after 4/4/94)
Power Driver Board Schematic
Dot Matrix Controller Board Schematic (Babcock display)
Dot Matrix Controller Board Schematic (Cherry display)
Fliptronic II Board schematic
Sound Board Schematic
Reference:
16-9834.1
