WPC pinball machines schematic manual set revised June 1994.
Original Bally/Williams WPC Schematic Manual revised June 1994
20 ledger size 11 x 17 inch fold out pages with sections for:
Power Wiring Diagram
CPU Board Schematic (Before 4/4/94)
Power Driver Board Schematic
Dot Matrix Controller Board Schematic (Babcock display)
Dot Matrix Controller Board Schematic (Cherry display)
Fliptronic II Board schematic
Sound Board Schematic
Reference:
16-9834
