BLACK ROSE (Bally) Manual WPC schematic

#16-20013-102

BLACK ROSE (Bally) pinball machine WPC Schematic Manual. March 1992. Very limited supply. Fair condition. Includes schematics for:

  • Fliptronic II
  • CPU Board
  • Power Driver Board
  • Dot Matrix Controller Board
  • Sound Board
  • Power Wiring Reference:
  • 16-20013-102

Hard copies of this manual are currently unavailable.

For a free .PDF version click here.
