Introduction to Bally Flipper Games - 1983 - Original
1983 Original 73 page comb bound, 8.5" x 11" novice level instruction book. Good condition.
Contains sections on:
- Terms & definitions
- Wire color codes
- Lubrication & adjustment instructions
- Relay, step-up, credit unit descriptions
- Assembly information
- Theory of operation for electromechanical pinball machines.
- Contains instructions on servicing and troubleshooting.
- 9 page appendix for troubleshooting Bally solid state games.
