ADDAMS FAMILY GOLD (Bally) WPC Schematic

#16-20017-102A
Availability
For Reference
Order
This product is currently discontinued. Email me if it becomes available

CALIFORNIA WARNING: This product can expose you to chemicals, including lead and DEHP, which are known to the State of California to cause cancer and birth defects, or other reproductive harm. For more information, go to https://www.p65warnings.ca.gov.

Product details

ORIGINAL THE ADDAMS FAMILY GOLD (Bally) pinball machine WPC Schematic Manual. Large fold-out 22 X 16 schematics. January 1992.

Schematics for:

  • Flipper software controller board

  • CPU Board

  • Power Driver Board

  • Dot Matrix Controller

  • Sound Board

  • Power Wiring

Hard copies of this manual are currently unavailable.

For a free .PDF version click here.

Reference:

  • 16-20017-102A


0.5 lb
