PARTY ZONE (Bally) WPC Schematic set

#16-20004-102
Availability
In Stock
Price
$32.99
Order

CALIFORNIA WARNING: This product can expose you to chemicals, including lead and DEHP, which are known to the State of California to cause cancer and birth defects, or other reproductive harm. For more information, go to https://www.p65warnings.ca.gov.

Product details

ORIGINAL NOS Bally PARTY ZONE WPC Schematic Manual. Full size fold-out pages.

Includes sections on:

  • CPU Board

  • Power Driver board

  • Dot Matrix controller

  • Sound Board

  • Power Wiring

Reference:

  • 16-20004-101 Manual

  • 16-20004-102 Schematic

  • Midway manufacturing

  • Original NOS direct from manufacturer.


5 oz
